5012C

The 5012C is a 2-conductor 24AWG 300V grey Xtra-Guard® 1 unshielded high performance cable with stranded tinned copper conductors, premium PVC insulation, nylon ripcord, premium PVC jacket and UV resistant material. This unshielded cable provide the smallest cable diameter for use in low-noise controlled environments. It provides added abrasion resistance to withstand mechanical abuse. Premium-grade PVC insulation and jacket for easier routing of cable in small spaces. Conductors are identified by different colours.

• CPR: Not Yet Qualified
• 7lbs Maximum pull tension
• 0.81mm Jacket thickness
• Provides resistance to oils per UL Oil Res I (60C OIL RES) and Class 43
• -35°C to 105°C Temperature range
