901-11020 HGBC1-3WH 5
线缆标记, Helagrip, 滑动式, V型切, 预打印, 5, 黑色, 白色, 3.5mm, 3 mm
图片仅用于图解说明，详见产品说明。
9 有货
需要更多？
9 件可于 5-6 个工作日内送达(英国 库存)
| 数量 | 价钱 (含税) |
|---|---|
| 1+ | CNY30.080 (CNY33.9904) |
| 10+ | CNY29.660 (CNY33.5158) |
| 100+ | CNY29.240 (CNY33.0412) |
| 250+ | CNY28.660 (CNY32.3858) |
| 500+ | CNY28.070 (CNY31.7191) |
| 1000+ | CNY27.560 (CNY31.1428) |
包装规格：每组 250
最低: 1
多件: 1
CNY30.08 (CNY33.99 含税)
品項附註
此订单的信息已添加到您的订单确认邮件、发票和发货通知中。
产品信息
制造商产品编号901-11020 HGBC1-3WH 5
库存编号2932391
产品范围Helagrip HGBC1-3
技术数据表
标记类型预打印
字符5
字符颜色黑色
标记颜色白色
标记尺寸3.5mm
电缆直径最大值3mm
电缆直径最小值1mm
标记材料PVC(聚氯乙烯)
产品范围Helagrip HGBC1-3
SVHC(高度关注物质)To Be Advised
产品概述
Helagrip Slide On, Pre-Printed Cable and Wire Markers from HellermannTyton have a specially designed profile to fit a range (1mm to 3mm) of cable diameters. Its chevron cut ends enable locking alignment of a series of pre-printed legends. Manufactured from a flexible, high-grade PVC compound that is indelibly marked. Ideally suited to panel building, mass transit, utilities, telecommunications and electrical contracting.
- Pack of 250 white cable markers with pre-printed black “5” legend
- Easy to apply -- simply slide on to cable, no special tools needed
- Fits bundle diameter 1mm to 3mm max.
- Chevron cut to lock markers together ensuring text remains in place
- Flexible PVC is cadmium free
- Markers are applied before termination takes place
- 3.5mm long
- Flammability rated UL94V0 (3mm)
- Specifications BS-2782-540B, BS-6746C, IEC 757, UL224
- Operating temperature range -65°C to +105°C; intermittent +135°C
技术规格
标记类型
预打印
字符颜色
黑色
标记尺寸
3.5mm
电缆直径最小值
1mm
产品范围
Helagrip HGBC1-3
字符
5
标记颜色
白色
电缆直径最大值
3mm
标记材料
PVC(聚氯乙烯)
SVHC(高度关注物质)
To Be Advised
技术文档 (1)
法律与环境
原产地：
进行最后一道重要生产流程所在的地区原产地：Great Britain
进行最后一道重要生产流程所在的地区
进行最后一道重要生产流程所在的地区原产地：Great Britain
进行最后一道重要生产流程所在的地区
税则号：39269097
US ECCN:EAR99
EU ECCN:NLR
RoHS 合规：是
RoHS
RoHS 邻苯二甲酸盐合规:是
RoHS
SVHC:To Be Advised
下载产品合规证书
产品合规证书
重量（千克）：.12
