22-01-3137

The 22-01-3137 is a 13-position crimp terminal housing from the KK 254 series (also known as the 2695 series), designed for wire-to-board signal applications. It features a single-row configuration with a 2.54 mm pitch and is made from UL 94V-0 rated nylon in a natural colour. It supports wire sizes from 22 to 30 AWG, is RoHS compliant, and rated for up to 250 V and 4 A per contact. This part is suitable for a wide range of commercial and industrial applications where compact and reliable interconnects are required.

• Series: KK 254 (2695 series)
• Number of Positions: 13
• Pitch: 2.54 mm (0.1 inch)
• Termination Style: Crimp
• Locking Feature: Friction ramp and polarization ribs for secure and accurate mating
• Wire Gauge Supported: 22AWG to 30AWG
• Voltage Rating: Up to 250V
• Material: UL 94V-0 rated nylon
