RDK-839

RDK-839 is a reference design for 12W power supply using TinySwitch™-4 TNY288PG.

• EcoSmart™ meets all existing and proposed energy efficiency standards including ErP
• No-load consumption less than 30mW, more than 300mW available in stand-by with 500mW input
• Greater than 84% average active-mode efficiency (DOE6 and EC CoC (v5))
• BP/M capacitor value selects power MOSFET current limit for greater design flexibility
• Accurately toleranced I2f parameter (-10%, +12%) reduces system cost
• Increases MOSFET and magnetics power delivery
• Reduces overload power, which lowers output diode and capacitor costs
• Integrated TinySwitch™-4 safety / reliability features
• Meets EN550022 and CISPR-22 Class B conducted EMI with greater than 12dBµV margin
• Meets IEC61000-4-5 class 3 AC line surge
