38104-F018-F00FL
IDC连接器, 2.54 mm, 1排, 4 触点, 电缆安装
- 制造商：
- 3M 3M
- 制造商产品编号:
- 38104-F018-F00FL
- 库存编号
- 3499530
- 产品范围
- 381 Series
- 技术数据表:
- 38104-F018-F00FL Datasheet
产品范围选择器 (381 Series)
查看全系列相关产品产品概述
3M™ link connector, 381 series featuring IDC termination offer a time-saving, reliable and field-installable wiring solution. It is suitable for wiring applications using 3-4 wires 22 to 16AWG and requiring 16V, 6.0A max. Common applications are branching and splicing into the existing network.
- Single-action IDC termination connector for T-branching and splicing of sensor and field networks
- Easy, labour saving and reliable IDC termination
- Easy field termination with No special wire preparation - No stripping, tinning or special tooling
- Compatible with conductor sizes 18 to 22AWG
- Can terminate with a common pair of pliers
- Semi-transparent color-coded covers for wire inspection and wire retention
- Hermaphroditic four-point contact mating structures
- T-tap termination enable mid-cable terminations without special preparation/handling of wires
- 5 Amp maximum current carrying capability per contact
- Latching mechanism maintains a reliable interconnection in demanding field applications
产品信息
技术文档 (1)
CAD 下载
--请选择...
✔
--请选择...
×
条款
CAD Models - Notice
CAD Models and drawings are provided to you on a revocable limited licence for your internal use only but remain the property of the manufacturer who retain all intellectual property rights and ownership. They are provided to assist you in decision making and as design guide but are not guaranteed to be error free, accurate or up to date and is not intended to be taken as advice.
Use of these CAD models and other options provided are downloaded and used entirely at your own risk and by continuing you confirm acceptance of the above.
可延期交货
由于市场条件的影响，交货时间仅供一般指导，可能会在短时间内发生变化
| 数量 | 价钱 (不含税) (含税) | 您所支付金额（含增值税） (不含税) |
|---|---|---|
| 1+ | CNY32.04 CNY36.21 | ( ) |
| 10+ | CNY26.92 CNY30.42 | ( ) |
| 100+ | CNY25.55 CNY28.87 | ( ) |
| 200+ | CNY22.41 CNY25.32 | ( ) |
| 500+ | CNY21.73 CNY24.55 | ( ) |
| 1000+ | CNY18.52 CNY20.93 | ( ) |
| 2000+ | CNY18.10 CNY20.45 | ( ) |
