HFBR-4513Z
光纤连接器, Vlink, 塑料光纤, 1mm, 塑料主体, HFBR-45XXZ
31,000 您现在可以预订货品了
| 数量 | 价钱 (含税) |
|---|---|
| 1+ | CNY10.440 (CNY11.7972) |
| 10+ | CNY8.010 (CNY9.0513) |
| 25+ | CNY7.940 (CNY8.9722) |
| 50+ | CNY7.870 (CNY8.8931) |
| 100+ | CNY6.090 (CNY6.8817) |
| 500+ | CNY5.080 (CNY5.7404) |
产品信息
产品概述
The HFBR-4513Z is a blue Simplex Latching Connector with crimp ring, designed for rugged applications requiring a greater retention force 80N (18lbs) than provided by a simplex non-latching connector. When inserting the simplex latching connector into a module, the connector latch mechanism should be aligned with the top surface of the horizontal modules or with the tall vertical side of the vertical modules. Misalignment of an inserted latching connector into either module will not result in a positive latch. The connector is released by depressing the rear section of the connector lever and then pulling the connector assembly away from the module housing.
- 80N at +25°C Typical connector to versatile link transmitters and receivers retention force
- 22N Typical connector to cable tensile force
- 35N Maximum connector to versatile link transmitters and receivers insertion force
技术规格
Vlink
1mm
HFBR-45XXZ
塑料光纤
塑料主体
Decamethylcyclopentasiloxane (21-Jan-2025)
技术文档 (1)
法律与环境
进行最后一道重要生产流程所在的地区原产地：Philippines
进行最后一道重要生产流程所在的地区
RoHS
RoHS
产品合规证书
