TRS3-0MCR01
热磁簧开关，0℃，±2.5℃，制造，轴向，引线式，TRS系列
需要更多？
| 数量 | 价钱 (含税) |
|---|---|
| 1+ | CNY74.810 (CNY84.5353) |
| 10+ | CNY65.160 (CNY73.6308) |
| 25+ | CNY60.560 (CNY68.4328) |
| 50+ | CNY58.540 (CNY66.1502) |
| 100+ | CNY58.510 (CNY66.1163) |
| 500+ | CNY58.470 (CNY66.0711) |
| 1000+ | CNY54.070 (CNY61.0991) |
产品信息
产品概述
TRS3-0MCR01 is a TRS3 series thermal reed switch. It is a highly reliable, precise temperature-sensitive switch ideal for energy conservation. Its unique proprietary design features a magnet and a temperature-sensing soft ferromagnetic substance called Thermorite®. The material’s magnetic flux density decreases as the temperature increases turning it into a paramagnetic substance at the Curie temperature. Typical applications include temperature detection and overheat monitoring of electric appliances, heat-retention heater control for rice cookers, defrost for air conditioners and vending machines, roll heater temperature control for copying machines, radiator water temperature detection for automotive electric fan control.
- Maximum opening/closing power is 35W
- Operating temperature of 0°C
- Make contact type, C shape fixing bar
- Lead terminal, 100V rated voltage
- High-speed response and long operational life
- Excellent environmental durability and extremely simple circuit design
- Compact, light and easy to handle
- Dust, explosion and corrosion-proof
- Excellent temperature accuracy of ±2.5°C
技术规格
0
连接
导线
0.15ohm
140 VAC / 200 VDC
500mA
-
± 2.5°C
轴向
TRS Series
35W AC / 10W DC
1mA
10°C
No SVHC (21-Jan-2025)
法律与环境
进行最后一道重要生产流程所在的地区原产地：Japan
进行最后一道重要生产流程所在的地区
RoHS
RoHS
产品合规证书
