PLD-25-700
LED驱动器, ITE和LED照明, 25.2 W, 36 V, 700 mA, 恒定电流, 90 VAC
可订购
制造商标准交货时间：31 周
有货时请通知我
| 数量 | 价钱 (含税) |
|---|---|
| 1+ | CNY125.150 (CNY141.4195) |
| 5+ | CNY119.300 (CNY134.809) |
| 10+ | CNY114.170 (CNY129.0121) |
| 50+ | CNY110.510 (CNY124.8763) |
| 100+ | CNY108.300 (CNY122.379) |
| 250+ | CNY106.090 (CNY119.8817) |
包装规格：每个
最低: 1
多件: 1
CNY125.15 (CNY141.42 含税)
品項附註
此订单的信息已添加到您的订单确认邮件、发票和发货通知中。
产品信息
制造商MEAN WELL
制造商产品编号PLD-25-700
库存编号4206581
产品范围PLD-25 Series
技术数据表
电源应用ITE和LED照明
输出功率最大值25.2W
输出电压最大值36V
输出电流700mA
LED驱动器模式恒定电流
输入电压最小值90VAC
输入电压最大值295VAC
产品范围PLD-25 Series
SVHC(高度关注物质)No SVHC (25-Jun-2025)
产品概述
PLD-25-700 is a PLD-25 series single output LED power supply. Safety standards are UL8750, CSA C22.2 No. 250.0-08, ENEC BS EN/EN 61347-1, BS EN/EN 61347-2-13 independent, BS EN/EN 62384, EAC TP TC 004, IP42 approved, design refer to UL60950-1.
- Universal AC input/full range (up to 295VAC), built-in active PFC function
- Constant current design, protections: short circuit / overtemperature
- Cooling by free air convection, fully isolated plastic case
- Class II power unit, no FG, IP42 design
- Suitable for LED related fixture or appliance (such as LED decoration or advertisement devices)
- 100% full load burn-in test, low cost, high reliability
- Suitable for dry / damp locations, 3 years warranty
- 700mA rated output current, 25.2W rated output power, 86% typical efficiency
- Working temperature rating range from -30 to +60℃
- Dimension (L x W x H) is 84 x 57 x 29.5mm
技术规格
电源应用
ITE和LED照明
输出电压最大值
36V
LED驱动器模式
恒定电流
输入电压最大值
295VAC
SVHC(高度关注物质)
No SVHC (25-Jun-2025)
输出功率最大值
25.2W
输出电流
700mA
输入电压最小值
90VAC
产品范围
PLD-25 Series
技术文档 (1)
法律与环境
原产地：
进行最后一道重要生产流程所在的地区原产地：China
进行最后一道重要生产流程所在的地区
进行最后一道重要生产流程所在的地区原产地：China
进行最后一道重要生产流程所在的地区
税则号：85044095
US ECCN:EAR99
EU ECCN:NLR
RoHS 合规：是
RoHS
RoHS 邻苯二甲酸盐合规:是
RoHS
SVHC:No SVHC (25-Jun-2025)
下载产品合规证书
产品合规证书
重量（千克）：.19
